| DT型電動推桿 |
|
| DT型主要技術(shù)參數(shù)及外形尺寸 |
型號 |
推力kg |
速度(mm/s) |
行程
S(mm) |
配用電機
Kw |
L
小 |
Lc
小 |
φA |
B |
C |
φE |
φF |
G |
H |
J |
M |
O |
P |
Y |
Z |
重量約
kg |
I |
II |
DT25△△ |
25 |
42 |
|
100～400 |
0.04 |
342+S |
155+S |
24 |
13 |
8 |
6 |
20 |
0 |
85 |
80 |
145 |
175 |
50 |
80 |
4-φ9 |
7.5 |
|
84 |
0.06 |
DT60△△ |
60 |
34 |
|
100～400 |
0.06 |
362+S |
140+S |
24 |
20 |
8 |
8 |
20 |
39 |
85 |
100 |
145 |
195 |
70 |
100 |
4-φ13 |
12 |
|
68 |
0.12 |
DT100△△ |
100 |
42 |
|
100～600 |
0.12 |
460+S |
240+S |
34 |
20 |
16 |
12 |
25 |
36 |
112 |
130 |
198 |
238 |
75 |
134 |
4-φ14 |
23 |
|
84 |
0.18 |
DT300△△ |
300 |
42 |
|
100～800 |
0.37 |
510+S |
245+S |
42 |
20 |
20 |
12 |
25 |
48 |
130 |
152 |
216 |
256 |
75 |
134 |
4-φ14 |
35 |
|
100 |
0.55 |
DT500△△ |
500 |
50 |
|
200～800 |
0.75 |
593+S |
276+S |
44 |
20 |
20 |
14 |
35 |
60 |
140 |
170 |
226 |
266 |
75 |
134 |
4-φ14 |
52 |
|
100 |
1.1 |
DT700△△△ |
700 |
50 |
|
200～1000 |
0.75 |
585+S |
267+S |
52 |
25 |
20 |
14 |
35 |
67 |
150 |
190 |
236 |
276 |
93 |
163 |
4-φ14 |
63 |
|
82 |
1.1 |
DT1000△△△ |
1000 |
50 |
|
200～1000 |
1.1 |
686+S |
283+S |
52 |
25 |
20 |
14 |
35 |
90 |
154 |
190 |
260 |
300 |
93 |
163 |
4-φ14 |
75 |
|
100 |
1.5 |
DT1600△△△ |
1600 |
50 |
|
200～1000 |
2.2 |
722+S |
248+S |
64 |
35 |
35 |
25 |
25 |
99 |
240 |
200 |
346 |
526 |
120 |
160 |
8-φ17 |
90 |
|
|
3.0 |
DT2500 |
2500 |
50 |
|
300～1600 |
4 |
912+S |
317+S |
78 |
35 |
35 |
25 |
40 |
123 |
300 |
230 |
436 |
666 |
140 |
190 |
8-φ |
230 |
|
|
DT3200 |
3200 |
50 |
|
300～1600 |
5.5 |
|
|
DT4000 |
4000 |
50 |
|
300～1600 |
5.5 |
|
|
DT5000 |
5000 |
6.6 |
|
300～1600 |
1.5 |
|
|
|
| 注:DT5000根據(jù)速度配備擺線針輪減速機 |
|
|
|
|
|
